Chapter 4 - Operation
4-3
4.1.3 ParameterSettingandAdjustme nt
1) Press [MODE] key until the desired parameter group is displayed.
2) Press [▲] or [▼] keys to move to the desired parameter number. If you know the desired parameter number,
you can program the parameter number within each parameter group in “Jump code”, except DRV group.
3) Press [PROG] key to go into the programming mode, the cursor starts blinking.
4) Press [SHIFT/ESC] key to move the cursor to the desired digit.
5) Press [▲] or [▼] keys to change the data.
6) Press [ENTER] key to enter the data. The cursor stops blinking.
Note: Certain parameters cannot be changed when the drive is running or AFN-94 [Parameter Lock] is activated.
(Refer to the parameter list, Chapter 5 for details).
EX) Changing Accel time from 10 sec to 15 sec
1) LCD keypad
Move to the desired parameter to change.
Press the [PROG] key.
A Cursor (■) will appear.
Use the [SHIFT] key to move the cursor.
Change the data using [▲], [▼] keys.
Press the
[ENTER]
key to save the value into memory.
The Cursor will disappear.
DRV► Acc. Time
01 _10.0 sec
DRV► Acc. Time
01 █10.0 sec
DRV► Acc. Time
01 _15.0 sec
DRV► Acc. Time
01 _10.0 sec
DRV► Acc. Time
01 _15.0 sec
To Next Page
