Chapter 5 – Parameter List
5-17
PARAM Description
LCD Keypad
Display Setting Range
Factory
Default
Adj.
During
Run Page
APP-21 2nd Deceleration Time
2nd Dec time
0 6000 sec 10 Yes
APP-22 2nd Base Frequency
2nd BaseFreq
30 - FUN-30 Hz 60 No 6-68
APP-23 2nd V/F Pattern
2nd V/F
Linear
Square
User V/F
Linear No
6-68
APP-24 2nd Forward Torque Boost
2nd F-boost
0 - 15 % 2 No
APP-25 2nd Reverse Torque Boost
2nd R-boost
0 - 15 % 2 No
APP-26 2nd Stall Prevention Level
2nd Stall
30 - 150 % 100 No
APP-27
2nd Electronic Thermal
Level for 1 minute
2nd ETH 1min
AFN-28 - 200 % 130 Yes
6-68
APP-28
2nd Electronic Thermal
Level for continuous
2nd ETH cont
50 - AFN-27
(Max. 150%)
120 Yes
APP-29 2nd Rated Motor Current
2nd R-Curr
1 - 200 A 3.6 No
APP-31
(Note 34)
Meter I Max Value
Meter I max
0 – 20 mA 20 Yes 6-68
APP-32
(Note 34)
Meter V1 Max Value
Meter V max
0 – 12 V 10V Yes 6-68
APP-33
(Note 34)
Meter P Max Value
Meter P max
0 – 100 kHz. 100kHz Yes 6-68
APP-40
(Note 28)
Number of Auxiliary
Motor Run Display
Aux Mot Run
View Only View Only
View
Only
6-69
APP-41 Aux. Motor Start Selection
Starting Aux
1 - 4 1 Yes
APP-42
Operation Time Display on
Auto Change
Auto Op Time
View Only View Only
View
Only
APP-43 The Number of Aux Motor
Nbr Aux`s
0 - 4 4 Yes
APP-44
Start Frequency of Aux.
Motor 1
Start freq 1
0 - FUN-30 Hz
49.99 Yes
6-70
APP-45
Start Frequency of Aux.
Motor 2
Start freq 2
49.99 Yes
APP-46
Start Frequency of Aux.
Motor 3
Start freq 3
49.99 Yes
APP-47
Start Frequency of Aux.
Motor 4
Start freq 4
49.99 Yes
APP-51
Stop Frequency of Aux.
Motor 1
Stop freq 1
0 - FUN-30 Hz
20.00 Yes
6-70
APP-52
Stop Frequency of Aux.
Motor 2
Stop freq 2
20.00 Yes
APP-53
Stop Frequency of Aux.
Motor 3
Stop freq 3
20.00 Yes
APP-54
Stop Frequency of Aux.
Motor 4
Stop freq 4
20.00 Yes
APP-58
Delay Time before
Operating Aux Motor
Aux start DT
0.0 - 999.9 sec 5.0 Yes 6-71
To Next Page
