Chapter 6 - Parameter Description [I/O]
6-44
I/O-28: Terminal Input Status
This parameter displays the input status of control
terminals M1-M8. P4-P6 are for future use.
Input
Term
P6 P5 P4 M8 M7 M6 M5 M4 M3 M2 M1
10
bit
9
bit
8
bit
7
bit
6
bit
5
bit
4
bit
3
bit
2
bit
1
bit
0
bit
OFF
status
0 0 0 0 0 0 0 0 0 0 0
ON
status
1 1 1 1 1 1 1 1 1 1 1
I/O-29: Multi-function input terminal filter time
constant
Debounces and sets the responsiveness of input
terminals M1-M8. Increasing the filter time is effective
when noise level is high. Increasing this parameter will
make response time slower and decreasing it will make
response faster.
Note: Set the parameter higher than 100msec when
attempting Inverter-Commercial Line Exchange
operation. This will prevent chattering during the
transition.
I/O-30: Jog Frequency
This parameter sets the jog frequency.
I/O-31~42: Step Frequency 4, 5, 6, 7, 8, 9, 10, 11, 12,
13, 14, 15
□
□
□
[Speed-L, Speed-M, Speed-H, Speed-X]
By setting M1, M2, M3 terminals to ‘Speed-L’,
‘Speed-M’ and ‘Speed-H’ respectively, the drive can
operate at seven preset frequencies set in DRV-21 ~
DRV-23 and I/O-31 ~ I/O-34. An additional terminal
M(x) can be set to Speed X to allow eight additional
preset frequencies (total of 15) using parameters I/O-35
~ I/O-42.
The step frequencies are determined by the
combination of M1, M2, M3 and Mx terminals as
shown in the following table.
I/O►
Step freq-4
31 40.00 Hz
Factory Default: 40.00 Hz
I/O►
Step freq-5
32 50.00 Hz
Factory Default: 50.00 Hz
I/O►
In status
28 00000000000
Factory Default: 00000000000
I/O►
Jog freq
30 10.00 Hz
Factory Default: 10.00 Hz
I/O►
Ti Filt Num
29 15 ms
Factory Default: 15 ms
To Next Page
