Chapter 6 - Parameter Description [APP]
6-68
APP-20 ~ APP-29: 2
nd
Functions
The purpose of these parameters is to provide the user
with a second set of motor parameters. This can be
useful on test stands with different motors or where a
user will be testing different types of applications
using two different motors. These parameters are
displayed only when one of the multifunction inputs
in parameters I/O-20 to I/O-27 is set to ‘2nd func’.
Contact closure to the input activates the 2
nd
Function
parameters. Drive must be stopped to activate the
second set of parameters.
Description 1
st
Functions 2
nd
Functions
Acceleration time
DRV-01
[Acc. time]
APP-20
[2nd Acc time]
Deceleration time
DRV-02
[Dec. time]
APP-21
[2nd Dec time]
Base Frequency
FUN-31
[Base freq]
APP-22
[2nd BaseFreq]
Volts/Hz mode
FUN-40
[V/F Pattern]
APP-23
[2nd V/F]
Forward torque
boost
AFN-68
[Fwd Boost]
APP-24
[2nd F-boost]
Reverse torque
boost
AFN-69
[Rev Boost]
APP-25
[2nd R-boost]
Stall prevention
level
FUN-60
[Stall Level]
APP-26
[2nd Stall]
ETH level for 1
minute
DRV-07
[ETH 1min]
APP-27
[2nd ETH 1min]
ETH level for
continuous
DRV-08
[ETH cont]
APP-28
[2nd ETH cont]
Motor rated current
DRV-05
[Rated-Curr]
APP-29
[2nd R-Curr]
APP-31: Meter I Max Value
APP-32: Meter V1 Max Value
APP-33: Meter P Max Value
When PI Control is selected in APP-02, these
parameters are used for scaling the maximum
feedback signal level at the maximum sensor pressure
set in I/O-87.
APP
►
2
nd
Acc time
20 5.0 sec
Factory Default: 5.0 sec
APP
►
2
nd
Dec time
21 10.0 sec
Factory Default: 10.0 sec
APP► meter V max
32 10.00 V
APP► meter I max
31 20.00 mA
APP► meter P max
33 100.0 kHz
