BENSHAW RSi SG Series User Manual

Chapter 8 – Options
8-9
Figure C. Conduit Boxes for 100 HP ~ 125 HP
Note: Choose the proper size of the Locknut and Bushing corresponding to the size of the conduit used.
VFD-RSI-125-SG-6B
PART NUMBER
VFD-RSI-100-SG-6B
600 125
600
VOLTS
100
HP
CONDUIT BOX FOR
13.91
[353.31]
14.57
[369.98]
FRONT
7.23
[183.59]
6.97
[176.99]
SIDE
7.09
[180.01]
BOTTOM
0.63
[15.98]
7.09
[180.01]
2.74
[69.55]
5.96
[151.49]
(3) 2.99" [76]
DIAMETER
KNOCKOUTS
(5) O.86" [22]
DIAMETER
KNOCKOUTS
14.57
[369.98]
7.23
[183.59]
2.36
[59.99]
TYP.
9.45
[239.98]
5.31
[134.98]
0.93
[23.60]
2.56
[65.00]
4.72
[119.99]
TYP.
2.56
[65.00]
TYP.
0.33
[8.33]
13.91
[353.31]
VFD-RSI-125-SG-4B
VFD-RSI-100-SG-4B
PART NUMBER
460 125
VOLTS
460 100
HP
