BENSHAW RSi SG Series User Manual

Chapter 6 - Parameter Description [DRV]
6-7
DRV-24: Output Current
This parameter displays the individual phase output
currents and the average of all phases as It (total).
DRV-26: Keypad Reference Mode
This parameter selects the mode of operation of the
drive when the keypad is removed.
DRV-26 Description
Minimum Spd
The drive continues to run at the
minimum speed, FUN-34.
Last Spd
The drive continues to run at the last
speed, when keypad was removed.
Preset Spd 1
The drive continues to run at Preset
Spd- 1 (DRV-21).
Stop
The drive stops according to Stop Mode
setting, FUN-23.
Fault
The drive cuts off its output and when
keypad is reconnected, displays Keypad
FLT.
Disable
(default)
Keypad Reference Mode is Disabled.
Note: This function only operates when DRV-03
and DRV-04 are set to Keypad.
DRV-27: Current, Phase U
DRV-28: Current, Phase V
DRV-29: Current, Phase W
DRV-30: Current, Ground
These parameters display the individual phase currents
and ground current.
DRV-91: Drive Mode 2
This parameter provides the user a second start source
to be selected by a digital input. This is often used
with a local / remote selector switch. To use this
function, one of the digital inputs must be set to [Loc /
Rem]. When the input is closed, the second set of
starting parameters is selected in DRV-91. When the
input is open; the drive uses the starting parameters in
DRV-03.
DRV-92: Frequency Mode 2
This parameter provides the user a second frequency
source to be selected by a digital input. This is often
used with a local / remote selector switch. To use this
function, one of the digital inputs must be set to [Loc /
Rem]. When the input is closed, the second set of
frequency parameters is selected in DRV-92. When
the input is open the drive uses the frequency
parameters in DRV-04.
Factory Default: Keypad-1
Factory Default: Fx/Rx-1
Ia= 0A Ib= 0A
Ic= 0A It = 0A
DRV ► KeyRefMode
26 Disable
DRV ► Ia Current
27 0.0 A
DRV ► Ib Current
28 0.0 A
DRV ► Ic Current
29 0.0 A
DRV ► Ground Curr
30 0.0 A
