Sewing preparation
24
2020-02 EN 5020077.20A.04
2.5 Raising or Lowering the Feed dog
> To raise the feed dog, push the feed dog lever to the right.
– The feed dog is raised when the first stitch is sewn.
> Slide the «Feed dog lever» left to lower the feed dog.
– The feed dog is lowered.
2.6 Using the slide-on table
When attached to the free arm, it expands the already existing sewing area.
> Raise the needle.
> Raise the presser foot.
> Switch the machine off and disconnect it from the power supply system.
> Push the slide-on table to the right over the free arm until it engages.
> To remove the slide-on table, pull the slide-on table over the free arm to the left.
