sk1: Service Menu
sk2: Mass Flow
sk1 sk2
Testrate 12345 cps
Output Curr : 10,0 mA
1,2345 g/cm3
Relay 1 : ON
Relay 2 : OFF
Relay 1 : ON
Input 1: OFF
Input 2: OFF
Input 3: ON
Set outputcur
Current : 9.0mA
View input cur.
Current: 12.0mA
High Voltage
Value : 800 V
sk1: Test calculate
sk2: I / O - Test
sk1 sk2 more
sk1: HV Adjustment
sk2: Status request
sk1 sk2 more
Save Default
Value : 850 V
Read Default
Value : 850 V
sk1: Reset Detector
sk2: Pt 100 adjust
sk1 sk2 more
Temperature =
45.2°C
Det. Temp. = 28 °C
For Detector - Reset
please press (sk 1 &
clear)
sk1: Measure Plateau
sk2: Request Plateau
sk1 sk2
Plateau measurement
running......
IIIIIIIII...........................
HV( 500): 817/s
HV( 560): 884 /s
HV( 620): 923/s
+ - done
sk1: Plateau
sk 2: Adj. Current out
sk 1 sk2 more
Current 1.8 mA
Offset: 4123
+
-
more
Current 18 mA
Offset: 345
+
-
more
For Pt 100-Adjust
please press
(sk2 & clear)
sk1: Adj. Cur. input
sk 2: Relay Delaytime
sk 1 sk2 more
Curr. Input Adjust
Set value 1.8 mA
Real value 1,7 mA
+ - more
Curr. Input Adjust
Set value 18 mA
Real value 17.5 mA
+ - more
Relay delay
Value: 50 ms
Flow
Value 87.00 m3/h
Ext. Mass Coun-
ter
Tons per cycle
Unit Mass Flow
[kg/h, t/h]
t/h
Range input
{at 20 mA]
Value: 100 m3/h
Erease mass
-
integrator
