6.4 Error Messages
6.4.1 Error Messages Reset
All error messages must be reset with <enter>.
Several simultaneously or consecutively occurring errors are stored in an error register in
the order of their appearance; they have to be reset individually by pushing <enter>
several times.
All errors are signaled via the “Error” output (Relay 16a/16c).
6.4.2 Error Messages during Operation
Error no. Message Cause, Notes Remedy
32 Wrong
password
The wrong password has been
entered to unlock the keyboard.
Push “enter” to reset error
message. Enter correct
password.
6.4.3 Error Messages during Calibration
Error no. Message Cause, Notes Remedy
10 Not
calibrated
Calibration incomplete Perform calibration
36 Missing ca-
lib. points
Not enough points entered for
selected calibration mode
Enter further calibration
points or select another
calibration mode
37 Curve not
clear
System could not calculate a
clearly rising or falling curve
Check calibration points for
input errors.
Select calibration mode
“linear”.
38 Error one-
point cali-
bration
Absorption coefficient = 0 Absorption coefficient = 0
39 Measuring
path not
defined
Measuring path = 0 Enter measuring path
56 Range
overflow
Measuring path = 0 Enter measuring path
