Beta ALP 4.0 User Manual

3
CHECKS AND MAINTENANCE
121
GB
Emptying oil from the tank
• Remove the four carter clamping screws
at the back of the motor.
• Unloosen the Q screw and let all of the
oil flow out of the tank.
• The first time you change the oil (see page
113), we suggest that you also clean the
metal filter which is positioned on the fi-
nal end of the oil tank.
The disassembling procedure is the follow-
ing:
• Unloosen the tank connecting carter mo-
tor tube.
• Using a monkey wrench, unscrew the joint
having a metal net in clockwise direc-
tion.
• Clean it with a jet of air
ATTENTION:
Always use eye protection during this pro-
cedure.

Beta ALP 4.0 Specifications

General

Displacement	349 cc
Final Drive	Chain
Rear Suspension	Monoshock
Front Brake	Single disc, 260 mm
Rear Brake	Single disc, 220 mm
Front Tire	90/90-21
Engine	Single cylinder, 4-stroke
