5
REPLACEMENTS
150
GB
REPLACING THE FRONT BRAKE PADS
The procedure for replacing the brake pads
is provided only for information. We rec-
ommend having the operation performed
by a BETAMOTOR authorized workshop.
ALP 4.0 FRONT BRAKE
Follow these steps to replace the pads:
Loosen the two screws A and remove the
brake caliper.
Loosen the two screws B.
Extract the brake pads.
To refit the parts, follow the reverse pro-
cedure, using blockage-threads on the
screws A.
WARNING:
When removing the front brake caliper,
take care not to damage sensor C.
To avoid braking problems, take special
care in ensuring that the screws are refit-
ted properly.
Whenever the brake disc is removed, ap-
ply blockage-threads to the screws when
refitting.
B
A
C

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Beta ALP 4.0 and is the answer not in the manual?

Beta ALP 4.0 Specifications

General IconGeneral
Displacement349 cc
Final DriveChain
Rear SuspensionMonoshock
Front BrakeSingle disc, 260 mm
Rear BrakeSingle disc, 220 mm
Front Tire90/90-21
EngineSingle cylinder, 4-stroke
