Beta ALP 4.0 User Manual

4
ADJUSTMENTS
147
GB
TENSIONING THE CHAIN
To ensure the drive chain a longer life, it is
advisable to periodically check its tension.
Always maintain the chain clean and lu-
bricated.
If the chain play exceeds 20 mm, tension
the chain by following these steps:
• Loosen the nuts on both arms of the rear
fork.
• Turn nut B until the desired chain tension
is obtained.
• Perform the same operation on nut B on
the other side of the swing arm until the
wheel is perfectly aligned.
• Clamp the counter-nut A on both arms of
the rear fork.
20 mm

Beta ALP 4.0 Specifications

General

Displacement	349 cc
Final Drive	Chain
Rear Suspension	Monoshock
Front Brake	Single disc, 260 mm
Rear Brake	Single disc, 220 mm
Front Tire	90/90-21
Engine	Single cylinder, 4-stroke
