Beta ALP 4.0 User Manual

5
REPLACEMENTS
154
GB
REPLACING THE BULBS MOTARD M4
FRONT
To replace the headlight bulb, disconnect
connectors A from the bulb and then re-
move rubber cap B.
Turn fastening flange C anticlockwise and
remove the bulb from the reflector.
Inserire la lampadina nuova(12V - 55/
60W) avendo cura di non toccare il bulbo
per evitare di comprometterne l'efficienza
e ruotare la flangia di fissaggio C in senso
orario fino a battuta.
Note:
In the MOTARD M4 version the rear light
and the indicators require no special main-
tenance as their light is produced by LEDs.
A
B
C

Beta ALP 4.0 Specifications

General

Displacement	349 cc
Final Drive	Chain
Rear Suspension	Monoshock
Front Brake	Single disc, 260 mm
Rear Brake	Single disc, 220 mm
Front Tire	90/90-21
Engine	Single cylinder, 4-stroke
