Beta ALP 4.0 User Manual

4
ADJUSTMENTS
148
GB
ADJUSTING THE HEADLIGHT
• The headlight beam is adjusted manually after loosening the screws on either side
of the headlight with an Allen key.
• Periodically check the direction of the beam. The beam can only be adjusted
vertically.
• Place the vehicle on level ground (but not on the stand) 10 metres from a vertical
wall.
• Measure the height of the headlight centre above the ground and then draw a
cross on the wall at 9/10 of the height of the headlight centre.
• Turn on the low beam, get on the motorbike and check that the headlight beam on
the wall is slightly lower than the cross drawn previously.
9/10 h
10 m
h

Beta ALP 4.0 Specifications

General

Displacement	349 cc
Final Drive	Chain
Rear Suspension	Monoshock
Front Brake	Single disc, 260 mm
Rear Brake	Single disc, 220 mm
Front Tire	90/90-21
Engine	Single cylinder, 4-stroke
