3
CHECKS AND MAINTENANCE
124
GB
FUME COLLECTING TUBE
Fume collecting tube A is located on the
left side of the vehicle, next to the shock
absorber, and comes out of the lower part
of the filter box. It is designed to collect
the fumes produced by the engine oil.
Should you find some oil in the tube, re-
move the cap at the lower end of the tube
and drain the oil, or the mixture of oil and
petrol, into a suitable container. Disposal
is to be made according to the regulations
in force.
Note
Empty the fume collecting tube every
3,000 km.
BRAKE PUMP OIL - BLEEDING THE
BRAKES
Front brake
Check that oil is present by looking through
oil level sight B. The minimum oil level
should never be lower than the mark on
sight B. To restore the oil level, loosen the
two screws C, lift cover D and pour in
fresh oil.
Keep the motor in a stable vertical posi-
tion, possibly blocking the handle-bar, so
as to avoid the brake oil from spilling out.
B
C
D
