3
CHECKS AND MAINTENANCE
129
GB
AIR FILTER
Follow these steps to gain access to the
air filter.
• Slightly raise the carter tank A as in fig-
ure.
• Remove plastic cover E and unscrewing
the three fixing screws B.
• Remove filter C after loosening the filter
retaining cover fixing screw D.
• Wash it with soap and water.
• Dry the filter.
• Wet the filter with filter oil and then re-
move the excess oil to prevent it from drip-
ping.
• If necessary clean the inside of the filter
box.
•
Refit the filter paying special attention to
the seal of the rubber gasket,
previously
greased so as to close better F.
Note:
If the filter is very dirty, first wash it with
petrol and then with water and soap.
If the filter is damaged, replace it immedi-
ately.
WARNING:
After each operation check that no object
is left in the filter box.
Clean the filter every time the vehicle is
used over rough ground.
