Beta ALP 4.0 User Manual

3
CHECKS AND MAINTENANCE
134
GB
Disassembling rear sides
• Unscrew the clamping screws N, after
having removed the rear handles and thus
slide the sides out.
Removing the fuel tank
• Remove screw I fixing the fuel tank to the
frame, detach the fuel cock line and then
remove the tank by pulling it towards the
rear of the vehicle.
Note:
The tank can be completely removed along
with the front sides, removing though, the
two lower screws G.
Disassembling front optic support group
• Detach all the electrical connections and
unscrew the three fixing screws L, one of
which located under the headlight.
Removing the headlight
• Remove the optic group N by unscrew-
ing the right and left screw M.

Beta ALP 4.0 Specifications

General

Displacement	349 cc
Final Drive	Chain
Rear Suspension	Monoshock
Front Brake	Single disc, 260 mm
Rear Brake	Single disc, 220 mm
Front Tire	90/90-21
Engine	Single cylinder, 4-stroke
