Beta ALP 4.0 User Manual

3
CHECKS AND MAINTENANCE
136
GB
Disassembling rear sides
• After removing the front side panels and
the grab handles, unscrew the two side
fasteners N and remove rear fairings M.
Subsequently remove the three screws O
and take off the side panels, disengaging
them from their catches.
M
N
O
Disassembling rear tail
• After removing the rear side panels, un-
screw the four screws P under the tail
fairing.
P
Removing the headlight
• Loosen the four screws Q and remove the
headlight assembly.
Q
Q

Beta ALP 4.0 Specifications

General

Displacement	349 cc
Final Drive	Chain
Rear Suspension	Monoshock
Front Brake	Single disc, 260 mm
Rear Brake	Single disc, 220 mm
Front Tire	90/90-21
Engine	Single cylinder, 4-stroke
