14
IRIS
Fig. 4.6
Fig. 4.5
remove the key from the drink dispensing chamber (Fig.4.5)
open the door of the distributor and remove the adhesive tape
from the components listed here below:
l cup turret (example in Fig.4.6)
l coin box
l sugar container
l weight on the spoon dispenser column
l coin mechanism cover / Master board
l product containers
The packing material must not be left accessible to
others, as it is a potential environmental pollution
sources. For the disposal contact qualified companies
authorized.
