IRIS
Fig. 6.27
Fig. 6.28
Fig. 6.29
6.6.3 Cup loading
Use only cups designed for automatic vending machines, with a
diameter of more than 70-74 mm, avoid compressing the cups
between themselves during the loading.
First filling
In installation phase with the cup dispenser completely empty,
operate as follows:
- take the cup dispenser with its cup column and push them
forward to make them rotate to the outside of the machine
(Fig. 6.27)
CAUTION!
Do not carry out this operation taking the cup
column only as some breakages may occur.
- Now load the cup column from above without manually rotate
it (Fig. 6.28).
- Once the loading has been completed, place the cup dispenser
back to its work position by rotating inside the machine.
- The cup dispenser is in the correct position only when it is
locked (Fig. 6.29).
