58
IRIS
49 kg
Fig.10.1
Fig. 10.2
10.0 ACCESSORIES
10.1 Basic furniture kit
On request two basic cabinets are available on which the automatic
distributor should be superimposed.
The difference between the two lies in the fact that one allows the
installation of the token box while the other does not.
N.B.: The IRIS espresso distributor has the chute to drain the
grounds directly into the cabinet already built-in as a standard
equipment; both cabinets are provided with two internal buckets
and the too full detector inside the bucket for liquids.
For the assembly and the coupling of the cabinet with the
distributor, proceed as follows:
- remove the 4 feet assembled on the table model (Fig.10.1)
- superimpose the distributor on the cabinet (Fig.10.2)
