38
IRIS
Fig. 7.9
7.2.6 PRICE- KEYS (Fig. 7.9)
Espresso version
Instant version
This menu shows the coupling of a price to the key or of a Vega
sector.
Line 1 shows the key or sector referred to while the desired price
no. has to be set on line 2.
To change number press keys P1 and P2 for incrementing or
decrementing respectively, P3 for cursor and P4 (Enter) to save
the selection.
