Installation, Operation and Maintenance Manual
September 2019
MAN720_IMVS2000v2_IOM Rev. 6
Section 11: Parts List
Parts List
Table 14.
Pos. Description Qty.
1 BARRIER CARD 1
2 LOGIC-DISPLAY CABLE 1
3 SCREW UNI 5931 M3x6 A4-70 2
4 SCREW UNI 5931 M5x22 A4-70 4
5 SCREW UNI 5931 M8x25 A4-70 4
6 LOGIC CARD 1
7 BEAD UNI 5923 M6x25 AISI 304 2
8 ANTI-LOOSENING WASHER UNI 8842-J6 2
9 NUT M6 UNI 5587 SS316 h6 Ch10 4
10 WASHER 6.4x2x1.6 UNI6592 AISI 316 2
11 SCREW PZ TYPE M3x10 7687 AISI 316 3
12 SCREW PZ TYPE M3x6 7687 AISI 316 7
13 LABEL – NAMEPLATE 1
14 RETAINING RING FOR SHAFT D.1O UNI7435 1
15 POSITION SHAFT AISI 316 1
16 SPACER M/F M3 H16 AISI 316 9(*)
17 SPACER M/F M3 H30.5 AISI 316 4
18 SPACER M/F M4/M3 H56 AISI 316 3
19 RING NUT M12 AISI 316 1
20 SINTERED METAL DISK AISI 316 1
21 PLUG 1/4’NPT 0-3 (**)
22 EARTH NAMEPLATE 1
23 BASE MANIFOLD 1
24 O-RING D=6.86 W=1.78 FLR 1
25 O-RING D=145.72 W=2.62 FLR 1
26 BUSHING FOR POSITION SHAFT 1
27 POSITION INDICATOR 1
28 PLUG M20 EP435 /M20x1.5 - OTM 4
29 POSITION LABEL 1
30 POSITION SENSOR ASSEMBLY 1
31 RELIEF BLOCK 1
32 BASE POWER CARD 1
33 BUS CARD (OPTIONAL) 1 (***)
34 COVER ASM FOR LOCAL DISPLAY 1
35 BASE COVER WITH WINDOW ASM 1
36 DISPLAY CARD 1
37 IMVS2000v2 PRESSURE SENSOR 0-3 (**)
99
