Section 6: Configuration Parameters
This section lists and describes the configuration parameters of the IMVS2000v2. For details about
the mapping of the parameters on the Local Operator Interface, see 7. For details about the mapping
of the parameters on the “Biffi-Assistant” SW tool (RS232 and Bluetooth), see [1]. For details about
the mapping of the parameters on the Bus Interfaces see the relevant manuals.
Table 5.
PARAMETERS OF THE “VIEW/SETUP MODE” MENU
PARAMETER NAME DESCRIPTION RANGE
DEFAULT
VALUE
R/W
(1)
AVAILABLE
ON (2) (3)
Dev. Mfr
(Device Manufacturer)
Biffi Biffi R
Local, Serial,
Bus
Dev. Name
(Device Name)
IMVS2000v2 IMVS2000v2 R
Local, Serial,
Bus
Dev. Tag
(Device Tag Name)
It is the named used the Bluetooth
connection.
The Bluetooth name is created as follows:
“BIFFI”+16 characters+ “-IMVS."
16 characters All “0” R/W
Local, Serial,
Bus
Dev. S.N.
(Device Serial Number)
20 characters All “0” R/W
Local, Serial,
Bus
Dev. Date
(Device Date of Manufacturing)
01-01-2014
31-12-2099
01-01-2014 R/W
Local,
Serial,Bus
SW L. Card.
(SW Logic Card revision)
xx.xx.xx R
Local, Serial,
Bus
SW D. Card.
(SW Display Card revision)
xx.xx.xx R
Local, Serial,
Bus
Act. Mfr
(Actuator Manufacturer)
12 characters All “ “ R/W
Local, Serial,
Bus
Act. Model
(Actuator Model)
20 characters All “ “ R/W
Local, Serial,
Bus
Act. Tag
(Actuator Tag Name)
20 characters All “ “ R/W
Local, Serial,
Bus
Act. S.N.
(Actuator Serial Number)
20 characters All “ “ R/W
Local, Serial,
Bus
Act. Pr. Size
(Actuator Pressure Size)
10 characters All “ “ R/W
Local, Serial,
Bus
Act. Date
(Actuator Date of Manufacturing)
01-01-2014
31-12-2099
01-01-2014 R/W
Local, Serial,
Bus
Valve Mfr
(Valve Manufacturer)
12 characters All “ “ R/W
Local, Serial,
Bus
Valve Model 20 characters All “ “ R/W
Local, Serial,
Bus
Valve Tag
(Valve Tag Name)
20 characters All “ “ R/W
Local, Serial,
Bus
Valve S.N.
(Valve Serial Number)
20 characters All “ “ R/W
Local, Serial,
Bus
Valve Date
(Valve Date of Manufacturing)
01-01-2014
31-12-2099
01-01-2014 R/W
Local, Serial,
Bus
Act. Mode
(Acting Mode)
”Single” must be set in case of:
• Single Acting actuator with
single SOV.
• Single Acting actuator with 2
SOVs in series or in parallel.
”Double” must be set in case of:
• Double Acting actuator with
dual SOVs.
”Double-S” must be set in case of:
• Double Acting actuator with
single SOV.
• Double Acting actuator with 2
SOVs in series or in parallel.
See 6.2 for details. If change it can
generate the CAL alarm (see 8).
Single,
Double,
Double-S
Single R/W
Local, Serial,
Bus
