September 2019
Installation, Operation and Maintenance Manual
MAN720_IMVS2000v2_IOM Rev. 6
MAN720_IMVS2000v2_IOM Rev. 6
Section 6: Conguration Parameters
Conguration Parameters
PARAMETERS OF THE “VIEW/SETUP MODE” MENU
PARAMETER NAME DESCRIPTION RANGE
DEFAULT
VALUE
R/W
(1)
AVAILABLE
ON (2) (3)
activOpen. Rot.
(Opening Rotation)
It defines the sense of rotation of the Opening Stroke.
“CW” = Clock Wise
“CCW”= Counter Clock Wise
If change it can generate the CAL alarm
(see Section 8).
CW, CCW CCW R/W
Local, Serial,
Bus
Fail Action
It defines the “direction” of the Fail Action.
“CL” = Fail To Close
“OP” = Fail To Open
If change it can generate the CAL alarm
(see Section 8).
CL, OP OP R/W
Local, Serial,
Bus
SOVs Qty
(SOVs Quantity)
It is applicable only if “Act. Mode” is “Single” or
“Double-S”.
It deals with the number of SOVs managed by the
IMVS2000v2.
”Simplex” = single SOV or 2 SOVs in series (it
depends on the value of “”PST Ser. SOVs”).
“Series” = 2 SOVs in series
“Parallel” = 2 SOVs in parallel
See Section 6.2 for details.
If change it can generate the CAL alarm
(see Section 8).
Simplex,
Series,
Parallel
Simplex R/W
Local, Serial,
Bus
Pr. S. 1-2
(Pressure Sensor 1-2)
It is pressure range of the pressure sensors #1 and
#2.
“None” = Pressure sensors 1 and 2 not present.
The pressure measurement unit (bar or psi) is
determined by the setting of the “Pres. M.U.
parameter.
None, 10,
20, 50, 100,
200, 400 bar
(None, 145,
290, 725,
1450, 2900,
5800 psi).
100 bar
(1450psi) R
Local, Serial,
Bus
Proc. S.
(Process Sensor)
It is pressure range of the process pressure sensor.
“None” = Process pressure sensor not present.
It is pressure range of the process pressure sensor.
The pressure measurement unit (bar or psi) is
determined by the setting of the “Pres. M.U.
parameter.
None, 10,
20, 50, 100,
200, 400 bar
(None, 145,
290, 725,
1450, 2900,
5800 psi).
None R
Local, Serial,
Bus
Set Pr. 1-2
(Set Pressure 1-2)
This command is used to set the pressure range of
the pressure sensors #1 and #2. It sets the value of
the parameter Pr. S. 1-2).
None,10, 20,
50, 100, 200,
400 bar
100 bar
(1450 psi) R/W Local, Serial.
Set Proc.
(Set Process Pressure)
This command is used to set the pressure range of
the process pressure sensor. It set the value of the
parameter Proc. S.
None, 10,
20, 50, 100,
200, 400 bar
None R/W Local, Serial.
RL A Cmd.
(Relay A Command)
If set as “Active," the DI “SOLENOID A CONTROL” is
consider as active despite of its real status.
If set as “Not Active”, the status of the DI “SOLE-
NOID A CONTROL” is determined by its status only.
Changing this parameter could cause the Actuator/
Valve stroking. See Section 5.2.2 for details.
Not Active,
Active
Not Active R/W
Local, Serial,
Bus
RL B Cmd.
(Relay B Command)
If set as “Active”, the DI “SOLENOID B CONTROL” is
consider as active despite of its real status.
If set as “Not Active.”, the status of the DI “SOLE-
NOID B CONTROL” is determined by its status only.
If “Act. Mode” ≠ “Double” and “SOV Qty” = “Sim-
plex” and “PST Ser. SOVs” = “Both” this input can
be used for launching the SOV TEST of the SOV B.
See Section 5.2.2 for details
Changing this parameter could cause the Actuator/
Valve stroking. See Section 5.2.2 for details.
Not Active,
Active
Not Active R/W
Local, Serial,
Bus
40
