BIFFI IMVS2000v2 - Normal Mode Menu

September 2019
Installation, Operation and Maintenance Manual
MAN720_IMVS2000v2_IOM Rev. 6
MAN720_IMVS2000v2_IOM Rev. 6
Section 6: Conguration Parameters
Conguration Parameters
6.1 Normal Mode Menu
Table 6.
PARAMETERS OF THE “VIEW/SETUP MODE” MENU
PARAMETER NAME DESCRIPTION RANGE
DEFAULT
VALUE
R/W
(1)
AVAILABLE
ON (2) (3)
Position
It is the value of the Position.
0% = Fully Closed, 100% = Fully Open.
0-100 % actual R
Local, Serial,
Bus
Pos. Req.
(Position Request)
It is the value of the Position Request.
0% = Fully Closed, 100% = Fully Open.
See Section 5.2.2.2 for details.
0-100 % actual R
Local, Serial,
Bus
Pres. 1
(Pressure 1)
It is the value of the Pressure of the pressure
sensor #1.
0 – 400 bar
(0 – 5800 psi)
actual R
Local, Serial,
Bus
Pres. 2
(Pressure 2)
It is the value of the Pressure of the pressure
sensor #2.
It is applicable only if the pressure sensor
#2 is present and enabled (“Act. Mode” =
“Double” or “Pr.2 En.” = “Yes”).
0 – 400 bar
(0 – 5800 psi)
actual R
Local, Serial,
Bus
Proc. Pres.
(Process Pressure)
It is the value of the Pressure of the process
pressure sensor.
It is applicable only if the process pressure
sensor is present and enabled (“Proc. S.” ≠
“None”).
0 – 400 bar
(0 – 5800 psi)
actual R
Local, Serial,
Bus
Date
It is the time “updated” by the RTC of the
IMVS2000v2.
00-00-00
23-59-59
actual R
Local, Serial,
Bus
Time
It is the date “updated” by the RTC of the
IMVS2000v2.
01-01-3013
31-12-2099
actual R
Local, Serial,
Bus
Alarms
It indicates the number of the active alarms.
See Section 5.2.7 for details.
0-255 actual R
Local, Serial,
Bus
Notes
(a) Specify the availability of the parameter on each interface: Local (Local Operator Interface),
Serial (RS232 and Bluetooth) and Bus Card (see relevant User Manual for details).
58
