Section 10: Installation – Start-Up
Installation – Start-Up
10.1 Installation in ambient with explosive dusts
Important
The installation and maintenance must be carried out in accordance with EN 61241-14 and
IEC 61214-14.
Special attention to these following points:
• before the assembly the joint surfaces must be greased with Aeroshell grease.
• the cable glands must have a protection degree at minimum IP66/68
(EN/IEC 60529).
• periodically verify the quantity of dust deposited on the enclosure and clean it in
the case the quantity becoming more than 5 mm.
10.2 Checks to be performed before installation
WARNING
Before the installation it is mandatory to check if the nameplate associated to the exten-
sion for additional entry specifies the appropriate degree of protection and ambient
temperature limits as requested by the Rules applicable to the plant/location where units
are installed.
If the IMVS2000v2 device is purchased separately, please proceed as follows before its
installation:
1. The electrical supply cables must be suitable for the power rating
(see the certificates delivered with the IMVS2000v2, if available, or the
IMVS2000v2 nameplate);
2. Gather the necessary tools for the assembly and setting of the IMVS2000v2 controls;
3. Check that the coupling dimensions of the actuator flange and stem meet the
IMVS2000v2 coupling dimensions;
4. Clean the actuator flange and remove anything that might prevent a perfect
adherence to the IMVS2000v2 flange and especially all traces of grease.
If a long storage period has occurred, before installing the IMVS2000v2, please:
1. Check the status of the O-ring seals;
2. Check the installation of the plugs or cable glands on the cable entries;
3. Check whether the enclosure covers of the IMVS2000v2 body are cracked or broken.
