Section 6: Conguration Parameters
Conguration Parameters
PARAMETERS OF THE “VIEW/SETUP MODE” MENU
PARAMETER NAME DESCRIPTION RANGE
DEFAULT
VALUE
R/W
(1)
AVAILABLE
ON (2) (3)
PST Info
The PST Type, PST Setpoint, PST Source, PST
SOV, PST Status, PST date and time, PST Break
and Travel Times, PST Break Pressure of the
selected PST (“PST ID”) are shown.
If “PST ID” > “PST Stored” than “all zeros” are
shown.
Using the Serial Interfaces, the “PST Info” is
“included” into the graph of Event (see [1]).
PST Type: PST
PST Source: “Base” (Baseline PST), “Manual”
(Manual PST), “Auto” (Automatic PST), “Exter-
nal Control” (SOV Test).
PST Status: “Not Done”, “Passed”, “Failed”,
“Conf. Err.”.
PST SOV: “A”, “B”, “AB.”
See Section 5 for details.
- - R
Local, Serial,
Bus
B. PST B. T.
(Baseline PST
Break Time)
If “Fail Act.” = “CL”
It is the time measured during the Baseline PST
that occurred for going from the Starting Open
Position to the 100% - “Op.Break Pos”. See 5.1.9
for details.
If “Fail Act.” = “OP”
It is the time measured during the Baseline
PST that occurred for going from the Starting
Closed Position to the “Cl.Break Pos.”
See Section 5.1.9 for details.
0–1000.0 sec 0 sec R
Local,
Serial,Bus
M. PST B. T.
(Manual PST
Break Time)
If “Fail Act.” = “CL”
It is the time measured during the last Manual
PST that occurred for going from the Starting
Open Position to the 100% - “Op.Break Pos”.
See Section 5.1.9 for details.
If “Fail Act.” = “OP”
It is the time measured during the last Manual
PST that occurred for going from the Starting
Closed Position to the “Cl.Break Pos”.
See Section 5.1.9 for details.
0–1000.0 sec 0 sec R
Local, Serial,
Bus
B. PST T. T.
(Baseline PST
Travel Time)
If “Fail Act.” = “CL”
It is the time measured during the Baseline PST
that occurred for going from the 100 - “Op.
Break Pos”.to the 100% - “Op.Break Pos”.
See Section 5.1.9 for details.
If “Fail Act.” = “OP”
It is the time measured during the Baseline PST
that occurred for going from the “Cl.Break Pos”.
to the “Cl.Break Pos”.
See Section 5.1.9 for details.
0–1000.0 sec 0 sec R
Local, Serial,
Bus
M. PST T. T.
(Manual PST
Travel Time)
If “Fail Act.” = “CL”
It is the time measured during the last Manual
PST that occurred for going from the 100 - “Op.
Break Pos”.to the 100% - “Op.Break Pos”.
See Section 5.1.9 for details.
If “Fail Act.” = “OP”
It is the time measured during the last Manual
PST that occurred for going from the “Cl.Break
Pos”.to the “Cl.Break Pos”. See Section 5.1.9
for details.
0–1000.0 sec 0 sec R
Local, Serial,
Bus
