BIGTREETECH Octopus MAX EZ V1.0 User Manual

BIGTREETECH Octopus MAX EZ V1.0 User Manual
6
Specifications
Dimensions
160mm x 100mm
for details please refer to
BIGTREETECH Octopus MAX EZ V1.0-SIZE.pdf
Mounting Size
Please refer to BIGTREETECH Octopus MAX EZ V1.0-
SIZE.pdf
MCU
ARM Cortex-M7 STM32H723ZET6 550MHz
Driver
Input Voltage
24V, HV(≤56V) Selectable
Motherboard
Input Voltage
VIN=DC12V or DC24V
Heated Bed
Input Voltage
BED IN=DC12V or DC24V
Logic Voltage
DC 3.3V
Heater Connection
Heated Bed (HB), Heater Cartridge (HE0, HE1, HE2, HE3
)
HB Port Max Curre
nt
10A Continuous, 12A Instantaneous
Heater Cartridge
Max Current
5.5A Continuous, 6A Instantaneous
Fan Port
2 pins CNC Fan (FAN0, FAN1, FAN2, FAN3),
4 pins CNC Fan (FAN4, FAN5, FAN6), Always On (24V F
AN x 2).
CNC Fan and MFAN Voltage Selectable (5/12/24V)
Fan Port Max Curr
ent
1A Continuous, 1.5A Instantaneous
Overall Max Curren
t
(Heater Cartridge+
Driver+All Fans)
＜12A
Expansion Port
BLTouch (Servos, Probe), PS-ON,
FWS, PWRDET, RGBx2, SPI,
IND-Probe, CAN, WIFI, TFT
Motor Driver
Support EZ5160, EZ2209, EZ2225, EZ2226, EZ2208, EZ
2130...
Driver Mode
SPI, UART
Motor Socket
Motor1, Motor2, Motor3 (Dual Motor Sockets), Motor4,
Motor5, Motor6, Motor7, Motor8, Motor9, Motor10
10 Channels in Total
Thermistor
5 x 100K NTC,
four of which are selectable for NTC and PT1000
Display
MINI12864 (FPC Connection), TFT Serial
PC Connection
Type-C
Supported Kinemat
ics
Cartesian, Delta, Kossel, Ultimaker, CoreXY
Recommended
Slicer/Console
Cura, Simplify3D, Pronterface, Repetier-host, Makerware
