ADVANCED USE MANUAL DD700
Note 4): it is possible to set Select Cell or Select cell data to obtain the output information relative to the
single cell or only one piece of information relative to all installed cells; setting one variable
automatically deletes the other.
By setting select cell, from 1 to number of cells, the variables take on the following meaning
The status variable takes on the meaning of cell status
The cell does not have a definitive address
The cell serial number differs from the registered one
The cell detects a low voltage
cell temperature outside of the range -40/+80°C
The cell is occasionally not connected
The cell has run an internal reset
By setting select cell data, from 1 to 6 as reported in the table below, the data variables
cell1/2/3/….n
Cell conversion to zero values
The status variable takes on the meaning of scale status
At least one cell is disconnected
At least one does not have a definitive address
The serial number of one or more cells differs from the registered serial
number
very different feed voltage on at least one cell
Temperature of one cell outside of the range -40/+80°C
None of the cells have a definitive address and the serial numbers are
different
All cells have the correct address but the serial numbers are different
The address of only one cell is not definitive and the serial number is
different
Feed voltage problem on one cell
At least one cell is occasionally not connected
At least one cell in warm-up phase at start-up
At least one cell has run an internal reset
