KBF / KBF P (E5.2) 02/2012 page 21/103
2.4 Instrument panel for KBF / KBF P
(1)
(2)
Figure 8: Triangle instrument panel
(1) Microprocessor program controller MB1 with 2-channel technology for temperature and humidity
(2) Switch for interior lighting (option)
3. Completeness of delivery, transportation, storage, and installa-
tion
3.1 Unpacking, and checking equipment and completeness of delivery
After unpacking, please check the unit and its optional accessories, if any, based on the delivery note for
completeness and for transportation damage. Inform the carrier immediately if transportation damage has
occurred.
The final tests of the manufacturer may have caused traces of the shelves on the inner surfaces. This has
no impact on the function and performance of the unit.
Please remove any transportation protection devices and adhesives in/on the unit and on the doors and
take out the operating manuals and accessory equipment.
CAUTION
Sliding or tilting of the unit.
Damage to the unit.
Risk of injury by lifting heavy loads.
∅ Do NOT lift or transport the unit using the door, the handle, or the lower housing.
Lift units size 115 from the pallet at the four lower corners with the aid of four people
Lift units size 240 from the pallet with the aid of six people or with a fork lifter. Set the
fork lifter only from the front or rear in the middle of the unit.
Lift units size 720 from the pallet using technical devices (fork lifter). Set the fork lifter
only from the front or rear in the middle of the unit.
∅ Do NOT set the fork lifter from the unit side.
If you need to return the unit, please use the original packing and observe the guidelines for safe lifting
and transportation (chap. 3.2).
For disposal of the transport packing, see chap. 17.1.
