Display 1 shows
06.00
(time of the selected shift point)
Display 2 shows Time 06:00
(entry of time of the selected shift point)
(actual setting: 6.00, i.e. 6 a.m.)
Enter the time 06:00 using arrow keys
Value is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows Ch1 = SP2: On
(entry of state of channel 1)
(actual setting: On)
Enter the state of channel 1
On using arrow keys
Setting is shown in display 2.
Press key EXIT
Display 1 shows
06.00
(time of the selected shift point)
Display 2 shows S1: 06:00 � -
(actual selection of the shift point: S1)
(actual setting: time 06.00, channel 1 ON)
Press program key
to select the next shift point
Display 1 shows
0000
Display 2 shows
Shiftpt.
(no function)
Press program key
Display 1 shows
0000
Display 2 shows Shiftpt. 2
(selection of the shift point)
(actual shift point: 2)
Select shift point 2 with key Value is shown in display 2.
Press program key
Display 1 shows
e.g. --.--
(time of the selected shift point)
Display 2 shows S2: --:--
(actual selection of the shift point: S2)
(actual setting: shift point not programmed)
Press program key
Display 1 shows
18.00
(time of the selected shift point)
Display 2 shows Time 18:00
(entry of time of the selected shift point)
(actual setting: 18.00, i.e. 6 p.m.)
Enter the time 18:00 using arrow keys
Value is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows Ch1 = SP2: Off
(entry of state of channel 1)
(actual setting: Off)
Enter the state of channel 1
Off using arrow keys
Setting is shown in display 2.
Press key EXIT
Display 1 shows
18.00
(time of the selected shift point)
Display 2 shows S2: 18:00 - -
(actual selection of the shift point: S2)
(actual setting: time 18.00, channel 1 OFF)
Press key EXIT twice
to select the next day of the week
