[Recording Form]
You can set up the recording form.
If you choose the ‘Rec Form’ menu, a small POP-UP menu will appear below; once you
choose either 3CH+1, 6CH+1, 12CH or 3CH+3, the POP-UP menu will disappear. The default
is ‘3CH+3'.
- ‘3CH+1’: 10-second ECG will be recorded as I, II and III for the first 2.5 seconds, aVR,
aVL and aVF for the next 2.5 seconds, V1, V2, V3 for the next 2.5 seconds
and V4, V5, V6 for the next 2.5 seconds. 1 channel of rhythm will be
recorded for 10 seconds at the bottom.
- ‘6CH+1’: 10-second ECG will be recorded as I, II, III, aVR, aVL and aVF for the first 5
seconds and V1, V2, V3, V4, V5 and V6 for the next 5 seconds.1 channel
of rhythm will be recorded for 10 seconds at the bottom.
- ‘12CH’: 12-channel rhythm will be recorded as I, II, III, aVR, aVL, aVF, V1, V2, V3, V4,
V5 and V6 at the same time for 10 seconds.
- ‘3CH+3’: 10-second ECG will be recorded as I, II and III for the first 2.5 seconds, aVR,
aVL and aVF for the next 2.5 seconds, V1, V2, V3 for the next 2.5 seconds
and V4, V5, V6 for the next 2.5 seconds. 3 channels of rhythm will be
recorded for 10 seconds at the bottom.
