40
(4) ST SEGMENT Setting
ST Level value is going to be up and down, when myocardial
infarction occurs. According to clinical study, all ST Level value
should be examined.
The program of BIONICS ST Level analyzes each ST Level value
regarding the LEAD I and LEAD II. It displayed fixed screen CH-1 to
LEAD 1 and CH-2 to LEAD II.
ST Level unit is mV, it displayed + during up and – during down.
1) ST Level Condition
As shown on the picture 22 , BIONICS ST Level program
measured by datum point -78ms(ISO) + 109ms (ST) and
centering of R Peak.
[picture 22] Datum point ST Level measurement
ST Point Range of Change
▶ By operating as detailed above, you can select each function of
the ECG mode.. (Menu of ST Level J Point setup change in
bottom)
