60
(2) Sidestream CO2
A. Connect on side of the gas outlet to the gas outlet of BPM-
1200(1010), and the other side to the air elimination system
of the hospital.
B. Open the spring-type door and connect the Filter-line
appropriately to the equipment. The other end is then
connected to the patient.
◈ The gas inspiring vacuum pressure (negative pressure) of the
gas elimination system should not exceed the pump outlet
standard of BPM-1200(1010), 1mmHg. Excessive pressure will
display the message of “OCCULSION” and it may damage the
BPM-1200(1010) product pump. During zeroing, the air
elimination system should be operating.
C. Respiratory is automatically changed during EtCO2
measurement. After stop the measurement, display the
calibrated impedance of chest.
◈ Connection of all tubes should be safe, and the nose cannula
should be kept away from the CO2-present area during the
warming up period (including the outlet of the ventilator and the
respiration of the user).
◈ Range for Measuring : 0 ~ 150bpm
D. If BPM-1200(1010) senses proper respiratory movement, it
displays EtCO2, FiCO2, and respiration rate after 3 seconds.
E. The respiratory waveform and data of EtCO2 is displayed. If
the waveform does not appear, set the Menu --> EtCO2 --->
TRACE -->ON.
F. If necessary, the size of the CO2 waveform can be adjusted
