Bionics BPM-1010 - EtCO2 Measurement (Optional); CO2 Gas Measurement

58
EtCO2 Measurement (Optional)
(1) CO2 Gas Measurement
The Resprionics of CO2 Module can be fitted onto BPM-1200(1010).
The Respironics CO2 Provides the function of EtCO2, and the
function to measure respiratory CO2 and respiration number using
the Side Stream/Main Stream.
◈ The maximum sampling rate of the nose tube is 50mL/min. The
product should not applied to patients who may experience
respiratory distress by the vacuum flow level.
◈ To prevent infection of the medical staff by the patient’s
respiration sample, the outlet of BPM-1200(1010) should be
connected to the air elimination system of the hospital.
Connection method
(Respironics_Mainstream Co2)
Co2 module connector portion connected "click" until you hear the connections.
(Respironics_Sidestream Co2)
WARNING
