57
▶ By operating as detailed above, you can select each function of
the IBP mode.
Set Mode
Range for Change
Explanation
Mode
ABP, FEM, PA, CVP, LA,
RA, ICP, SP
Set the level according to the
measurement site of BP.
Change the alarm setting range
according to level.
Speed
6.25, 12.5, 25, 50mm/sec
Set the speed of IBP waveform
Scale
Maximum / 10 ~ 80mmHg
Set the scale of IBP waveform
Center
0 ~ 120mmHg
Set the base line of IBP waveform
Calibration
Start / Cancel
Adjust the zero point of the
transducer
TRACE
ON / OFF
Set the display of waveform
* Adjust the zeropoint of the transducer : In order to obtain accurate results, make
sure to adjust the zeropoint of the transducer before measuring the patient.
* Fixed : Basic value according to the established label (ABP:0~200,
CVP:0~50, ICP:0~50, PAP:0~50)
<Composition of IBP KIT>
BIOTRANS Model Name
Explanation
BT4812-3
IBP D.P.T Monitor kit
AY-IBP-010
IBP Cable Y-Type(Double)
