Bizerba SC II Series - 5.4.2 Opening and Closing the Thermal Print Head

Operating instructions SC II Device and operating controls
61429850113 en-US 33 / 107
Closing
Fold the printer lid
2
down.
Illustration21: Close SC II 800 printer lid
5.4.2 Opening and closing the thermal print head
NOTICE
– The thermal strip is coated with a glass passivation layer and
must not be touched or cleaned with hard objects.
Label printer in SC II 100/200
Open
Place one finger underneath the red grip
element
1
.
Pull the grip element towards you until
the
1
thermal print head
2
disengages
and moves downwards.
Illustration22: Label printer in SC II 100
Close
Place your finger on the red grip element
1
.
Press the thermal print head
2
upwards against the printer roller and then backwards
until the thermal print head engages.
