Maintenance Operating instructions SC II
90 / 107 61429850113 en-US
Clean the deflection roller and take-up pin.
Open the printer lid and print head.
Remove the label roll.
Remove glue residues from parts
1
.
Illustration75: deflection pin, take-up pin
Clean paper deflector
Pull the paper deflector
2
out sideways.
Clean the paper deflector using the
Bizerba "LR label remover". The "LR-la-
bel remover" may not be used to clean
thermal strips.
Push the paper deflector
2
in sideways.
Illustration76: Paper deflector
8.1.3 Cleaning products for printer
Ordering information

Bizerba SC II Series Specifications

General

Display	LCD
Readability	1 g / 2 g / 5 g
Material	Stainless steel
Power Supply	100-240 V AC, 50/60 Hz
Operating Temperature	-10°C to +40°C
Connectivity	Ethernet, RS232
Application	Retail, industrial
Platform Size	300 x 400 mm / 400 x 500 mm
