Device and operating controls Operating instructions SC II
36 / 107 61429850113 en-US
Insert new ticket roll
Open side cover and printer cover [}30].
The thermal bar
4
must not be opened.
Remove the empty core of the ticket roll.
Insert a new ticket roll
2
.
Lead the ticket paper to the printer roller
5
according to paper feed.
After a short time an automatic paper in-
feed is activated.
Illustration26: Paper track for ticket paper /
SC II 800
Move paper forward using the <Paper infeed> key.
Confirm status message "Ticket printout
or" by pressing <Enter>.
Illustration27: Status message
Close side and printer cover [}30].

Bizerba SC II Series Specifications

General

Display	LCD
Readability	1 g / 2 g / 5 g
Material	Stainless steel
Power Supply	100-240 V AC, 50/60 Hz
Operating Temperature	-10°C to +40°C
Connectivity	Ethernet, RS232
Application	Retail, industrial
Platform Size	300 x 400 mm / 400 x 500 mm
