BK Precision 2190E User Manual

104
Save Waveforms to USB Flash Drive
Table 3.47 – Save Waveform to USB Flash Menu
Option
Setup
Description
Type
Waveforms
Menu for the Storage/Recall
waveforms.
Save to
File
Select save location to USB flash
drive.
Save
Select to save to USB.
Figure 3.50– Save Waveform Screen (To Flash Drive)
To save waveforms to a USB flash drive, follow the steps below:
1. Input a sine signal to channel 1, press the “AUTO”
button.
2. Press the “SAVE/RECALL” button to enter the
“SAVE/RECALL” display menu.
3. Press the “Type” option button to select “Waveforms”.
