62
Table 3.23 – Alternate Trigger Edge Mode Function Menu 1
Option
Setting
Description
Type
Alternate
When using alternate trigger, the triggered
signal comes from two vertical channels. In
this mode, you can observe two irrelative
signals at a time.
Channels
CH1-CH2
Set the trigger channels
Source
CH1
CH2
Set trigger type information for CH1 signal
Set trigger type information for CH2 signal
Mode
Edge
Set trigger type of vertical channel signal to
edge
Next Page
Page 1/2
Go to the second page of the TRIGGER
Menu.
Table 3.24 – Alternate Trigger Edge Mode Function Menu 2
Option
Setting
Description
Slope
Triggering on rising edge.
Triggering on falling edge.
Triggering on rising edge and falling edge.
Set up
Enter “Trigger setup menu” (See Table
3.17).
Next Page
Page 2/2
Go to the back to the first page of the
TRIGGER Menu.
