106
Example 4: Generate a Pulse Waveform
Generate a pulse waveform with 5 kHz frequency, 5 V high level, -1 V low level, 40 μs pulse
width and 20 ns delay.
⚫ Set the Frequency.
1. Press Waveforms → Pulse → Frequency/Period and choose Frequency, which will display in
a blue color.
2. Input ‘5’ from the keyboard and choose the unit ‘kHz’. The frequency is set to 5 kHz.
⚫ Set the HighLevel.
1. Press Amplitude/HighLevel and choose the HighLevel which will display in a blue color.
2. Input ‘5’ from the keyboard and choose the unit ‘V’. The high level is set to 5 V.
⚫ Set the LowLevel.
1. Press Offset/LowLevel and choose the LowLevel which will display in a blue color.
2. Input ‘-1’ from the keyboard and choose the unit ‘V’. The low level is set to -1 V.
⚫ Set the PulWidth.
1. Press PulWidth/DutyCycle and choose PulWidth which will display in a blue color.
2. Input ‘40’ from the keyboard and choose the unit ‘μs’. The pulse width is set to 40 μs.
⚫ Set the Delay.
