BK Precision 4050B Series User Manual

35
Follow the steps below to browse and select a predefined arbitrary waveform.
1. Press the Waveforms button.
2. Go to the second page of waveform options by pressing the 1/2 . softkey. .
3. Select and press the Arb softkey from the menu.
4. Select Built-in from the parameter menu and there will be a table on the display area
showing the available built-in waveforms. The menu will display the waveform
categories: Common, Math, Engine, etc.
5. After selecting the category (selected category will be highlighted in blue), use the
rotary knob to select the desired predefined waveform (selected waveform will be
highlighted in white).
Figure 22 - Arbitrary Waveform
Figure 23 - Built-in Waveforms
