Chapter 4: Configuration
724-746-5500 | blackbox.com
Page 25
4.1.4.2 Accessing the Browser-Based Configuration Utility
1 Temporarily connect the ServSwitch Agility Dual with VNC unit and a computer via a network, as discussed left.
2 Run a web browser on your computer and enter the IP address of the ServSwitch Agility Dual with VNC unit, e.g.
http://169.254.1.33
The default settings are as follows:
Agility Dual with VNC transmitter Agility Dual receiver
System port 169.254.1.33 169.254.1.32
Teaming port 169.254.1.43 169.254.1.42
Where the addresses of a unit is not known, perform a manual factory reset (see section 4.1.3) to restore the default
addresses.
The opening page of the ServSwitch Agility configuration utility should be displayed and you can now use on-screen help for
details of the functions that you wish to perform.
You can find further information about the configuration pages within the Appendix A later in this guide
