Timecode Input
There are five timecode input options available when recording.
Video Input Selecting video input will take the embedded timecode from SDI and HDMIsources
with embedded SMPTE RP 188 metadata. This will maintain sync between your SDI or
HDMI source and the file recorded onHyperDeckExtreme.
External XLR Click this option when using timecode via external XLR from analog basedsources.
Internal Use this option to record time of day timecode via the built in timecode generator.
Last Clip Regen By selecting ‘last clip regen’ for your timecode input, each file will start one frame after
the last frame of the previous clip. For example, if your first clip ends on 10:28:30:10,
the next clip timecode will start at 10:28:30:11.
Preset Preset will use the set timecode under ‘timecode preset’.
Timecode Preference
For NTSC sources at frame rates of 29.97 or 59.94, you can select ‘drop frame’ or
‘non-drop frame’ recording. If the source is unknown, tap on default. This will maintain the
standard of the input, or default to drop frame if there is no valid timecode.
Timecode Preset
You can set your time code manually by tapping on the pencil icon and entering the start time
code via the touchscreen keypad.
Timecode Output
Tap on clip or timeline to select your timecode output
Select your timecode options for your SDI outputs.
Timeline Tap the timeline option to output your timeline timecode.
Clip The clip option will output the timecode of your clip.
39Settings
