Blackmagicdesign HyperDeck Extreme 8K HDR User Manual

Command Reply No Remote Notes
0x85 0x05 BMDPlay Acknowledge Disabled
2 Bytes 16bit big endian
signed integer, which
is the speed to play at,
where a value of 100 = 1.0x
1 Byte unsigned integer,
which is the playback flags
bitfield, where
bit 0 = Loop
bit 1 = SingleClip
1 Byte unsigned integer,
which is the playback type,
where
0 = Play
1 = Jog
2 = Shuttle
3 = Var
1 Byte unsigned integer,
which is the scroll boolean
flag, where 0 evaluates as
false and all other values
evaluate as true.
0x80 0x06 BMDClip Acknowledge Disabled
RS-422 Developer Information
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Byte 0
0 0 Cassette out Servo Ref 0 0 0 Local
Byte 1
Standby 0 Stop 0 Rewind Forward Record Play
Byte 2
Servo Lock 0 Shuttle Jog Var Direction Still 1
Byte 3
Auto Mode 0 0 0 Aout Set Ain Set Out Set In Set
Byte 4
Select EE Full EE Loop Playback 0 0 0 0 0
Byte 5
Scroll 0 0 0 Loop Clip 0 0 0
Byte 6
0 Lamp Still Lamp Fwd Lamp Rev 0 0 0 0
Byte 7
0 0 0 0 0 0 0 0
Byte 8
0 0 Near EOT EOT 0 0 0 Rec Inhibit
Byte 9
0 0 0 0 0 0 0 0
497RS-422-Steuerung
