Command Reply No Remote Notes
A - Advanced Media Protocol
0xA1 0x01 AutoSkip Acknowledge Disabled
8-bit signed number of
clips to skip from current
clip
0xAX 0x15 ListNextID IDListing Enabled
when x = 0 single clip
request when x = 1, #
clips can be specified in
the send data
0x20 0x29 ClearPlaylist Acknowledge Disabled
0x41 0x42 SetPlaybackLoop Acknowledge Disabled
Bit 0 loop mode enable,
0=false 1=true
Bit 1 is single clip/timeline
0=single clip
1=timeline
0x41 0x44 SetStopMode Acknowledge Disabled
0 = Off
1 = Freeze on last frame
2 = Freeze on next clip
3 = Show black
0x4f 0x16 AppendPreset Acknowledge Disabled
2 Bytes for the length N
of the clip name
N Bytes for each character
of the clip name
4 Byte in point timecode
(format is FFSSMMHH)
4 Byte out point timecode
(format is FFSSMMHH)
Blackmagic Extensions
0x82 0x02 BMDSeekToTimelinePosition Acknowledge Disabled
16-bit big endian fractional
position [0..65535]
0x81 0x03 BMDSeekRelativeClip Acknowledge Disabled
One-byte signed integer,
which is the number of
clips to skip (negative for
backwards).
0x87 0x04 BMDScrubTimelineDelta Acknowledge Disabled
1 Byte unsigned integer,
which is the whence, where
0 = Set
1 = Current
2 = End
4 Byte 32bit big endian
unsigned integer, which is
the delta to scrub by.
1 Byte signed integer,
which is the delta’s sign,
where a value less than 0
will set the delta scrub to a
negative value.
1 Byte unsigned integer,
which is the unit of time to
scrub by, where
0 = Frames
1 = Milliseconds
97RS-422 Control
