Using HyperDeck

Command Reply No Remote Notes

0 - System Control

0x00 0x11 DeviceTypeRequest

NTSC: 0xF0E0

PAL: 0xF1E0

24P: 0xF2E0

Enabled

1 - Slave Response

0x20 0x00 Stop Acknowledge Disabled

0x20 0x01 Play Acknowledge Disabled

0x20 0x02 Record Acknowledge Disabled

0x20 0x10 FastFwd Acknowledge Disabled

0x21 0x11 JogFwd1 Acknowledge Disabled

0x22 0x11 JogFwd2 Acknowledge Disabled

Treated as N=1;

Same as JogFwd1

0x21 0x12 VarFwd1 Acknowledge Disabled Uses ShuttleFwd1

0x22 0x12 VarFwd2 Acknowledge Disabled

Treated as N=1;

Same as VarFwd1

0x21 0x13 ShuttleFwd1 Acknowledge Disabled

0x22 0x13 ShuttleFwd2 Acknowledge Disabled

Treated as N=1;

Same as ShuttleFwd1

0x20 0x20 Rewind Acknowledge Disabled

0x21 0x21 JogRev1 Acknowledge Disabled

0x22 0x21 JogRev2 Acknowledge Disabled

Treated as N=1;

Same as JogRev1

0x21 0x22 VarRev1 Acknowledge Disabled Uses ShuttleRev1

0x22 0x22 VarRev2 Acknowledge Disabled

Treated as N=1;

Same as VarRev1

0x21 0x23 ShuttleRev1 Acknowledge Disabled

0x22 0x23 ShuttleRev2 Acknowledge Disabled

Treated as N=1;

Same as ShuttleRev1

0x20 0x30 Preroll Acknowledge Disabled

0x24 0x31 CueData Acknowledge Disabled

0x20 0x34 SyncPlay Acknowledge Disabled

Supported RS-422 Commands
