Blackmagicdesign HyperDeck Studio User Manual

Contents
HyperDeck Disk Recorders
5 Getting Started
Introducing HyperDeck 5
Plugging in Video Sources 6
Connecting Video Outputs 7
Recording Video 7
Playing Video 8
10 Using HyperDeck
About SSDs 10
Choosing a Fast SSD 10
Preparing SSDs for HyperDeck 11
HyperDeck Utility 12
How to Update Your HyperDeck Software on Mac OS X 12
How to Update Your HyperDeck Software on Windows 12
Selecting Your Video Format in HyperDeck Utility 13
About Ultra HD 4K 14
Setting Up Ultra HD 4K Recording 14
Setting Up Ultra HD 4K Playback 14
Accessing Your Clips 15
Mac OS X 15
Windows 15
Status Indicators 15
Using the Display Menu on HyperDeck Studio Models 16
Selecting Timecode Source 17
SDI Start/Stop Recording 17
Timecode Run Recording 18
Shuttling with HyperDeck Shuttle 18
Jog and Shuttle with HyperDeck Studio Models 18
Ref Input 19
RS-422 Control 19
What is RS-422 Control? 19
Using an External RS-422 Controller 19
Daisy-chaining for Crash Recording 20
Supported RS-422 Commands 21
RS-422 Developer Information 25
Installing the HyperDeck Shuttle Mounting Plate 26
27 Using Your Favorite Editing Software
Capturing video via Thunderbolt 27
Capturing from SSD 27
Simultaneous Capture and Recording 27
Avid Media Composer 28
Setting up 28
Capturing live via Thunderbolt 29
Apple Final Cut Pro 7 30
Setting up 30
Capturing live via Thunderbolt 30
Adobe
®
Photoshop
®
CC 32

Blackmagicdesign HyperDeck Studio Specifications

General

Built in Control Panel	Yes
Bit Depth	10-bit
Video Connections	HDMI
Audio Connections	Embedded in SDI/HDMI, XLR
Control	RS-422, Ethernet
Power Supply	Internal
SDI Rates	3G
Computer Interface	Ethernet
SD Video Standards	NTSC, PAL
HD Video Standards	720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60
SDI Compliance	SMPTE 259M, 292M, 424M
HDMI Compliance	HDMI 1.4
Recorder Media	SSD, HDD
External Control	RS-422, Ethernet
Recorder Control	RS-422, Ethernet
Storage	SSD, HDD
Frame Rates	720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Chroma Subsampling	4:2:2
Timecode	Yes
